MSB-Compact Mobile Tower Platform

62 x 80 cm footprint 62 x 80 cm footprint 405 cm total height 405 cm total height 60 kg mast top payload 60 kg mast top payload 190 kg, one engineer 190 kg, one engineer
Compact - No Equipment

Some sites will not take a full size tower. A courtyard with a metre of clearance, a car park deck under three metres, an indoor hall, a pavement job behind hoarding. The MSB-Compact is the Mobile Tower Platform built for those places: a galvanised steel cabinet of 62 by 80 cm, a three part telescopic mast reaching 405 cm total height, and 60 kg of payload at the mast top. A portable CCTV tower that one engineer sets down with a forklift, ready for the cameras and floodlights you already stock.

Request a Quote

Built for sites where space is tight

Fits where the others do not

A ground footprint of 62 by 80 cm and a cabinet height of 180 cm. That clears the doorways, loading bays and car park decks that block a full size unit.

One engineer, no civil works

Position the unit, extend the four stabilisers, level it on the spirit level and raise the mast with the manual winch. No trenching and no grid connection needed.

Your equipment, your brand

A four spoke mast top takes fixed cameras, a PTZ unit or a floodlight. Inside the cabinet there is room for batteries or fuel cells, with an IP66 patch box already fitted.

Locked down and vandal resistant

Galvanised steel throughout, a fully lockable cabinet with cylinder lock and provision for a second lock, roof climb protection and a vandal resistant cable conduit.

Download the Compact Line brochure

Dimensions, drawings and mounting details for the MSB-Compact and the MSB-Roadbox, in one PDF.

  • Technical specifications and dimensions
  • Mast top and cabinet mounting options
  • Transport, trailer and storage options
Compact Line Brochure

Choose your deployment method

Tow it in as the MSB-Roadbox

Place the MSB-Compact on the TMT-750 minitrailer and the combination tows behind a van. Same cabinet, same mast, no forklift needed at the far end.

TMT-750 Trailer
62 x 80 Base (cm)
MSB-Roadbox Combination
3 part, 80/60/40 mm Mast
Cabinet
62 x 80 x 180 cm
Weight
190 kg
Total height
405 cm
Mast top payload
60 kg

Real-world applications

Where the MSB-Compact goes in when a full size platform will not fit

City centre construction with no room for a full size base

[TE BEVESTIGEN: klantnaam] | Netherlands

A city centre plot with hoarding a metre from the pavement leaves no space for a 100 by 100 cm base. Two MSB-Compact units stand inside the hoarding instead, covering the gate and the material store from the same 4G router.

Units deployed
2 Platforms
Footprint per unit
62 x 80 cm
Total height
405 cm
Set up
1 Engineer
Let's talk about your site More clients cases

Our products

MSB-Roadbox

Compact on a TMT-750 minitrailer

MSB6-Basic Plus

6 m mast with anti climb protection

MSB6-Premium

6 m mast, heavy duty cabinet

MSB-Edge

Off grid platform with angled solar side
View All Products and Trailers

Receive Personal Advice

Our team of experts is ready to help you find the right solution for your security needs. Fill out the form below and we will get back to you as soon as possible.

Gawain Guedry
Gawain Guedry
Director, North American Sales and Operations

Get in Touch

Have questions about our Mobile Tower Platforms? Our sales team is ready to help you find the perfect solution for your security needs.

Contact our Sales Manager

Ga****@***************************al.nl
+1 702 885 2069

Common questions about the MSB-Compact

Dimensions, certification, transport and delivery. What installers and integrators ask before specifying the Compact.

The cabinet measures 62 by 80 cm at the base and stands 180 cm high, at a total weight of 190 kg. With the three part mast extended the total height is 405 cm. That gets the unit through a standard roller door and onto a deck that blocks a 100 by 100 cm base.

Up to 60 kg on a four spoke mast top: fixed cameras, a PTZ unit, a floodlight or a combination of these. Cabling runs double inside the mast and an IP66 patch box is fitted in the cabinet for the electronics.

The cabinet is galvanised steel throughout and the manual winch is CE approved at 550 kg. The MSB-Compact is CE certified by TUV Rheinland, produced under an ISO 9001 quality management system, and ANSI certified for deployments outside Europe.

Yes. The four spoke mast top takes standard brackets, and the platform stays brand neutral, so ONVIF cameras and your own VMS both fit. The equipment on top remains your choice and your existing investment stays in use.

Security integrators, rental companies and regional distributors run this platform under their own name. The partner programme covers technical support, co-marketing and preferential pricing. Reach out and let us know what fits your market.

Forklift slots on two sides and lifting eyes on top, or place the unit on the TMT-750 minitrailer and tow it as the MSB-Roadbox. Stock is held in the warehouse in the Netherlands, which keeps delivery inside Europe short. Outside Europe, count on eight to ten weeks.
